ELECTRONIC COOLANT VALVE TEST SYSTEM

Thermal management is a challenge, especially with e-mobility. Maintaining optimal temperatures in dynamic conditions is critical to the efficiency and effectiveness of batteries, motors, and inverters. The coolant valve has evolved from simple on/off to complex multi-port components, required to perform at extremes.

Ensure CV™ is a purpose-built test system with a scalable/variable number of flow measurement and control circuits (to match the number of ways or ports of the valve).

WE SPEAK THE LANGUAGE

Screen Shot 2021-03-03 at 11.27.41 PM.png

test new coolant valve

prototypes and end-of-line

The system was designed to characterize and benchmark new electronic coolant valve prototypes and validate ones at the end of the production line (internal leak with coolant, external leak with air, air-to-coolant correlation).

From the subsystems used to the support, you receive after the system is delivered, our Section ID™ database allows us to combine best practices with your specific application.

Subsystems - Fluid and Hydraulic Component Test Systems. Oil pumps, water pumps, coolant valves, etc.

Subsystems

Robust fluid conditioning subsystems, engineered for prolonged use between extremes.

Measurement - Fluid and Hydraulic Component Test Systems. Oil pumps, water pumps, coolant valves, etc.

Measurement

From simple thermostats to advanced multi-way valves. Accurately measure key parameters for auxiliary and/or advanced control valves.

Physical Interface - Fluid and Hydraulic Component Test Systems. Oil pumps, water pumps, coolant valves, etc.

Physical Interface

Coolant flex hose and flow sights available for part samples.

Control - Fluid and Hydraulic Component Test Systems. Oil pumps, water pumps, coolant valves, etc.

Control

Simulate various test conditions (i.e. hot/cold fluid and air temperature, thermal shock) according to industry standards.

Electrical - Fluid and Hydraulic Component Test Systems. Oil pumps, water pumps, coolant valves, etc.

Electrical

Designed for international power sources and safety considerations with minimal to no modifications.

DAQ - Fluid and Hydraulic Component Test Systems. Oil pumps, water pumps, coolant valves, etc.

Air Testing

Air-to-fluid correlation for functional and performance testing.

(Production-only)

FlashFreeze™ - Fluid and Hydraulic Component Test Systems. Oil pumps, water pumps, coolant valves, etc.

Fluidify™

Rapidly cool or heat the valve body and test fluid from +130°C to -40°C.

Cycle through extremes quickly, with a rate of change of up to 13°C/min.

Support - Fluid and Hydraulic Component Test Systems. Oil pumps, water pumps, coolant valves, etc.

Support

ATA Assist™ allows you to submit a request for assistance 24/7.

ATA Accurate™ is an annual on-site system calibration which meets the ISO17025 standard accredited by A2LA.




Thinking about building a custom test machine?

It’s quicker with Section ID™.

e-Mobility has created a more diverse world of testing. These new requirements are being defined and implemented rapidly, as the race to produce electric vehicles speeds up with it. In an effort to reliably control the temperatures of EV motors, batteries, etc, the single 2-way valve just won’t cut it. Now, we are seeing the development of more advanced multi-way valves (ie. Tesla Octovalve) that contain complex electronics and circuits. ATA is prepared with a platform of pre-defined modules that you can assemble and develop test systems around building-like blocks. This allows you to begin testing faster than any custom-engineered option.

We call it Section ID™. Answer a few questions about your component, the parameters, and the test application; now your test system is defined and ready for order.

Custom strike.png

CUSTOM ENGINEERING

  • Requirements-driven from the customer (you)

  • Designed from scratch

  • Built for the first time

  • Debugging and commissioning to get things right

  • ATA doesn't do this

Section ID Final Animation.gif

SECTION-ID™

  • Pre-engineered modules based on current and future technical challenges

  • Application engineering to select the right modules for your requirements

  • Tailored or custom modules as necessary

  • Modules assembled quickly on our production line, then custom elements are handled by project management methodology

  • Little debugging or commissioning required

Electric+oil+pump+test+bench

ATA ENSURE™

  • Turn-key systems for a specific application

  • Built with Section ID™

  • Wide variety of options for different component configurations or performance envelopes

  • Fastest delivery, lowest risk

  • International compatibility

Section ID - Online Logo.png
testing copy.png

OUTSOURCE YOUR COOLANT VALVE TESTING

Whether you are seeking specific testing expertise for a new product or looking for additional test capacity, we are ready to support you. ATA test solutions are suitable for performance characterization, durability testing, and audit validation.

  • Solenoid switching/mixing valves

  • Rotary switching/mixing valves

  • Thermostat

  • …and more

  • Solenoid shutoff valves

  • Rotary shutoff valves

  • Discrete proportional valves

  • Advanced valves (4-ways or more)

Blue copy.jpg

systems integration

Advanced modular solutions for fluid and hydraulic testing birthed from over 15 years of engineering experience. Allow us to make your validation process easier and production line more efficient, with a test solution that can quickly be tailored to your application.

Reliable systems that create a testing advantage:

  • Measurement and control expertise

  • Handling for all types of flows

  • Risk reduction


Apply Ensure CV™ to your coolant valve application.
